If you’re a hardy adventure-seeker who doesn’t subscribe to the concept of labels, you’ve come to the right place.
The Search XR A2 expands expectations.
Whether you’ve put in months of planning, or you just decided to turn right on a whim, the Search XR A1 is built to thrive off the beaten path and is up to whatever adventure you chase.
Aluminum adventure frame maximizes comfort and reduces fatigue.
- Different geometries between drop bar, flat bar and suspension models.
- A little slacker and longer than your typical Gravel machine.
- Internal routing keeps cables secure and protected from the elements.
- Up to 50mm tire clearance for comfort and control on-and-off road.
- Ample water-carrying capacity and stealth accessory mounts.
Specification
| Frame |
Butted Aluminum, Smooth Welds
BB Standard: BB86/BB92, Press Fit
Color: Beige / Grey
|
| Fork |
Full Carbon, Through Axle
|
| Bottom Bracket |
FSA BB386EVO for BSA
|
| Headset |
Sealed Cartridge Bearing
|
| Stem |
Norco SL Aluminum, 31.8mm Clamp, 70mm (49), 80mm (52), 90mm (55), 100mm (58), 110mm (61)
|
| Handlebar |
Norco Super Flare Aluminum, 16 Degree Flare, 40cm (49), 42cm (52), 44cm (55), 46cm (58, 61)
|
| Saddle |
Selle Royal Gravel with Cutout
|
| Seatpost |
|
| Pedals |
City Resin
|
| Grips |
Griptacular Shockproof Tape
|
| Rear Derailleur |
Shimano GRX RD-RX400 Shadow RD+
|
| Front Derailleur |
Shimano GRX FD-RX400
|
| Crank |
FSA Omega Modular 46/30 AGX+, 170mm (49, 52), 172.5mm (55, 58), 175mm (61)
|
| Shifters |
Shimano Tiagra ST-4700
|
| Cassette |
Shimano CS-HG50, 11-36T, 10 Speed
|
| Chain |
KMC X10
|
| Brakes |
Front: Tektro MD-C550 Dual-Piston Mechanical Disc, Resin Pads, Rear: Tektro MD-C550 Dual-Piston Mechanical Disc, Resin Pads
|
| Brake Levers |
Shimano Tiagra ST-4700
|
| Rims |
Alloy Pinned, 28H, 23mm ID
|
| Front Hub |
12x100mm Through Axle, 6 Bolt
|
| Rear Hub |
12x142mm Through Axle, HG, 6 Bolt
|
| Tires |
Front: Vittoria Terreno Dry 700x38c, Rear: Vittoria Terreno Dry 700x38c
|
| Disc Rotors |
Tektro 6-Bolt, 160mm
|
SIze Chart
| 49 / X-Small |
From 5'1" to 5'5"
|
| 52 / Small |
From 5'4" to 5'8"
|
| 55 / Medium |
From 5'7" to 5'11"
|
| 58 / Large |
From 5'10" to 6'2"
|
| 61 / X-Large |
From 6'1" to 6'5"
|
