| Frame |
FORM™ Alloy | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-4™ Adjustable Geometry | 2 Position Axle | 140mm Travel. FORM™ Alloy Rear Triangle |
| Fork |
Fox 36 Float EVOL GRIP Performance Series 150mm | 27.5 = 37mm Offset | 29 = 44mm Offset |
| Front Travel |
150mm |
| Shock |
Fox Float X Performance | Sealed Bearing Eyelet | 20x8mm F Hardware | XS - SM = 190x45mm | MD - LG - XL = 210x52.5mm | Size-Specific tune in FAQ |
| Rear Travel |
140mm |
| Headset |
FSA ZS56|66 Reach Adjust| 0mm Cups Installed | +/- 5mm Cups Included | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5" Crown Race |
| Stem |
Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm |
| Handlebar |
Rocky Mountain AM | 780mm Width | 25mm Rise | 9° Backsweep | 5° Upsweep | 31.8 Clamp |
| Grips |
ODI Elite Pro Lock On |
| Brakes |
Shimano MT6120 4 Piston | Metal Pads |
| Shifters |
Shimano XT |
| Rear Derailleur |
Shimano XT |
| Cranks & Chainring |
Race Face Ride Cinch | 32T | 24mm Spindle | Crankarm Length: XS -SM = 165mm | MD - XL = 170mm |
| Bottom Bracket |
Shimano SM-BBMT500 |
| Cassette |
Shimano SLX 10-51T |
| Chain |
Shimano M6100 |
| Front Hub |
Rocky Mountain SL Sealed Boost 15mm |
| Rear Hub |
Shimano XT Boost 148mm | 28H |
| Spokes |
2.0 Stainless |
| Rims |
WTB ST Light i30 TCS 2.0 Tubeless | 28H / Tubeless Ready - Tape / Valves Incl |
| Tires |
F: Maxxis Dissector 2.4 WT EXO Tubeless Ready // R: Maxxis Dissector 2.4 WT EXO Tubeless Ready |
| Seatpost |
X Fusion Manic Alloy 30.9mm | Shimano MT500 Remote | XS = 125mm | SM = 150mm | MD - LG = 170mm | XL = 200mm |
| Saddle |
WTB Volt Race 142 |
